KAMPUNG LAUT
ZONE 3
Zone 3 consists of 21 buildings located at the Northern part of Masjid Kampung Laut and one main research building located at the Southwest of Masjid Kampung Laut.
BUILDING LIST
1. Teratak Wan Ghazi
2. Rumah @ Kampung Dalam Pandan
3. Rumah @ Kampung Dalam Pandan
4. Galleri Wayang Kulit
5. Serunding Factory
6. Rumah @ Kampung Dalam Pandan
7. Rumah @ Jalan Kampung Laut (No. 15)
8. Rumah @ Jalan Kampung Laut
9. Rumah @ Jalan Kampung Laut
10. Rumah @ Jalan Masjid Lama (Lot 1547)
11. Rumah @ Kampung Laut 2 (Lot 928)
12. Rumah @ Near Kampung Dalam Pandan
13. Rumah @ Jalan Kampung Laut 2 (No. 16040)
14. Rumah @ Near Kampung Dalam Pandan
15. Rumah @ Near Kampung Dalam Pandan
16. Rumah @ Jalan Kampung Laut 2 (No. 16040)
17. Rumah @ Jalan Masjid Lama (No. 271)
18. Rumah @ Jalan Masjid Lama (No. 235)
19. Rumah @ Jalan Masjid Lama (No. 227)
20. Rumah @ Jalan Masjid Lama (No. 237)
21. Azrini Serunding
LANDMARK
A
MASJID KAMPUNG LAUT
17
Rumah @ Jalan Masjid Lama (No. 271)
12
Rumah @ Near Kampung Dalam Pandan
18
Rumah @ Jalan Masjid Lama (No. 235)
19
Rumah @ Jalan Masjid Lama (No. 227)
13
Rumah @ Jalan Kampung Laut 2 (No. 16040)
15
Rumah @ Near Kampung Dalam Pandan
16
Rumah @ Jalan Kampung Laut 2 (No. 16040)
20
Rumah @ Jalan Masjid Lama (No. 237)
14
Rumah @ Near Kampung Dalam Pandan
21
Azrini Serunding
11
Rumah @ Kampung Laut 2 (Lot 928)
7
Rumah @ Jalan Kampung Laut (No. 15)
10
Rumah @ Jalan Masjid Lama (Lot 1547)
Rumah @ Jalan Kampung Laut
8
Rumah @ Jalan Kampung Laut
9
5
Serunding Factory
2
Rumah @ Kampung Dalam Pandan
6
Rumah @ Kampung Dalam Pandan
4
Galleri Wayang Kulit
3
Rumah @ Kampung Dalam Pandan
A
MASJID KAMPUNG LAUT
1
Teratak Wan Ghazi
MAIN RESEARCH BUILDING
1. Teratak Wan Ghazi
Year :
1935 (Original)
6.153833 N, 102.230564 E
Coordinate:
Address:
JLN KAMPUNG LAUT, KAMPUNG LAUT, 16040 TUMPAT, KELANTAN
Building Typology:
Residence
Building Owner:
Wan Mohd Ghazali bin Wan Salleh Fathi
Building Condition:
- Well Maintained
Architectural Style:
Traditional Malay House
Major Material:
- Cengal Wood, Seraga Kitab Timber
Significant Features:
- Decoration: Extensive wooden decorations reflecting traditional craftmanship
- Layout: A raised threshold (bendul) and a split-level liviing area
Historical Background:
The house belongs to Wan Mohd Ghazali bin Wan Salleh Fathi, born on 12 May 1943. His father was a businessman in Brunei, while his mother was a housewife. Following his father's footsteps, he continued the family business and carried on the family legacy.
He married at the age of 37 and has three children-two sons and one daughter. Currently, he resides in Kota Bharu with his wife and children. During his youth, he enjoyed playing the violin. He received his education at Maahad Muhammadi.
This house has been vacant for the past 10 years following the passing of Encik Wan's parents. The family began living here in 1943, and the house originally belonged to Encik Wan's grandfather, being passed down through generations until it came into his care.
​
This house holds deep memories and a long family history. Built in 1935 on family-owned land, it has sheltered several
generations. In 1943, Encik Wan Mohd Ghazali's uncle's family became one of the early occupants, further rooting this house in the family's heritage. However, after the major flood in 2014, the house began to be abandoned.
Building Space
Elevations
Front Elevation
Right Elevation
Left Elevation
Rear Elevation
Significant Features
COLOURED GLASS WINDOW (ANGIN KACA BERWARNA)
Providing soft colored light, privacy and aesthetic value
1
2
CASSETTE WALL (DINDING KASET)
Maintain the strength of the board while providing a layered visual pattern
' TIANG '
Main pillars of the support for the building
3
4
' KOLONG RUMAH '
The space under the house (stilted void). Function: flood protection, underfloor ventilation, storage, and social activity space
TRADITIONAL ' BUMBUNG PERABUNG '
Good water flow, complex shape for upper attic ventilation and traditional aesthetics
5
6
CARVING OF ' AWAN LARAT ' MOTIF (UKIRAN MOTIF AWAN LARAT)
Ventilation + light control, also important for decorative shadows
'TUNJUK LANGIT' & 'BUAH BUTON / BUTIR'
Ventilates the upper attic, facilitates inspection, and provides a traditional aesthetic. wood end protector from weather and cracking
7
8
VENT BLOCK (LUBANG ANGIN KONKRIT)
Ventilates the upper attic, facilitates and provides a traditional aesthetic
10
TIMBER LOUVERS 'TEBAR LAYAR'
(DINDING TEBAR LAYAR)
Rain protection, monolithic appearance & limited ventilation
WOOD CARVING WITH FLOWER MOTIF 'KERAWANG TEBUK TEMBUS'
For cross ventilation and light without completely opening up the space
9
w.jpg)
12
BALUSTRADE (SUSUR TANGAN)
Safety function, movement guide, and decorative element
FLOWER MOTIF WOOD CARVING
(TEBUK TEMBUS UKIRAN BUNGA)
Perforated concrete blocks for wall/basement ventilation, durable, low cost, safety & ventilation
11
w.jpg)
14
TRADITIONAL MALAY FLOWER MOTIF
For some ventilation, more for decoration and protection from rain
'SUSUN SIREH' WALL
(DINDING SUSUN SIREH)
Maintain the strength of the board while providing a layered visual pattern
13
BUILDING LIST
2. Rumah @ Kampung Dalam Pandan
Building Owner: Puan Rahmah
Year: 1945
Architect: N/A
Coordinate: 6.16 N, 102.230592 E
Address:
KAMPUNG DALAM PANDAN, 16200 WAKAF BHARU, KELANTAN.
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass
Significant Features:
- Opening: Timber opening
- Material: Most of the material is made by timber & Singgora roof covering
Historical Background :
The traditional long house originally belonged to the owner's mother-in-law, Puan Rahman. It is one of the few remaining long houses where elderly traditionally occupied the central space. The owner now lives here with her grandchild after her husband's passing.
Remark: N/A
3. Rumah @ Kampung Dalam Pandan
Building Owner: N/A
Year: 1945
Architect: N/A
Coordinate: 6.154766 N, 102.231018 E
Address:
KAMPUNG DALAM PANDAN, 16200 WAKAF BHARU, KELANTAN.
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass, Brick
Significant Features:
- Decoration: Nicely made railings and carvings that look attractive
Historical Background : N/A
Remark: N/A
4. Galleri Wayang Kulit
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.155329 N, 102.231155 E
Address:
KAMPUNG DALAM PANDAN, 16200 WAKAF BHARU, KELANTAN.
Building Typology: Gallery
Building Condition: Abandoned
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass, Brick
Significant Features:
- Structure: Two storeys building with Minangkabau style roofing
Historical Background :
It used to be a wayang kulit gallery for traditional shadow puppet shows. It was abandoned after the owner died from illness.
Remark: N/A
5. Serunding Factory
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.155819 N, 102.230879 E
Address:
KAMPUNG DALAM PANDAN, 16200 WAKAF BHARU, KELANTAN.
Building Typology: Serunding Factory
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Corrugated Metal Roof, Wood, Stained Glass, Brick
Significant Features: N/A
Historical Background : N/A
Remark: N/A
6. Rumah @ Kampung Dalam Pandan
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.155479 N, 102.230917 E
Address:
KAMPUNG DALAM PANDAN, 16200 WAKAF BHARU, KELANTAN.
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Modern Malay House
Major Material:
- Corrugated Metal Roof, Wood, Stained Glass, Brick
Significant Features: N/A
Historical Background : N/A
Remark: N/A
7. Rumah @ Jalan Kampung Laut (No. 15)
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1573508 N, 102.229841 E
Address:
NO. 15 JALAN KAMPUNG LAUT, 16200, TUMPAT KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass
Significant Features: N/A
Historical Background : N/A
Remark: N/A
8. Rumah @ Jalan Kampung Laut
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1578628 N, 102.23 E
Address:
JALAN KAMPUNG LAUT, 16200, TUMPAT KELANTAN
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass, Concrete Finished By Tiles (Staircase)
Significant Features:
- Decoration: Decorative timber plank for sunshading & Carved ornamental timber baluster and column
Historical Background : N/A
Remark: N/A
9. Rumah @ Jalan Kampung Laut
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1579868 N, 102.2303880 E
Address:
JALAN KAMPUNG LAUT, 16200, TUMPAT KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Traditional Malay House
Major Material:
- Corrugated Zinc Roofing, Wood, Stained Glass, Brick, Metal Railings
Significant Features:
- Ventilation: Ventilation timber board at the top of wall & Ventilation block at the lower level for moisture control
Historical Background : N/A
Remark: N/A
10. Rumah @ Jalan Masjid Lama (Lot 1547)
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1573468 N, 102.231033 E
Address:
LOT 1547, JALAN MASJID LAMA, KG LAUT, 16040 PALEKBANG, KELANTAN.
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Modern Malay House
Major Material:
- Corrugated Zinc Roofing, Wood, Stained Glass, Brick
Significant Features:
- Decoration: Climbing plants along the facade
- Ventilation: Ventilation block at the lower level for moisture control
Historical Background : N/A
Remark: N/A
11. Rumah @ Kampung Laut 2 (Lot 928)
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1548334 N, 102.229767 E
Address:
LOT 928, KG LAUT 2, 16040 TUMPAT KELANTAN.
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Corrugated Zinc Roofing, Wood, Stained Glass, Brick
Significant Features:
- Ventilation: Ventilation block at the lower level for moisture control
Historical Background : N/A
Remark: N/A
12. Rumah @ Near Kampung Dalam Pandan
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1573595 N, 102.2299253 E
Address:
NEAR KAMPUNG PANDAN , 16200 , WAKAF BHARU , KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile, Wood, Stained Glass
Significant Features:
- Material:Well-preserved wood material
- Decoration: Kerawang sisip angin & Balustrade design
Historical Background : N/A
Remark:
- Rarely occupied
- A stilted, compact linear residential form
13. Rumah @ Jalan Kampung Laut 2 (No. 16040)
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1571365 N, 102.2302028 E
Address:
16040 , JALAN KAMPUNG LAUT 2 , 16210 , WAKAF BHARU , KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Early Modern Period Architectural (Era Awal Moden)
Major Material:
- Singgora Tile, Wood, Stained Glass, Concrete
Significant Features:
- Material: Well-preserved wood material & Zinc roof
- Ventilation: Vent block & Breeze block
- Decoration: Kerawang & Balustrade design
Historical Background : N/A
Remark:
- Rarely occupied (Only in Eid Fitri)
- Main residential mass organized around a projecting frontal veranda
14. Rumah @ Near Kampung Dalam Pandan
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1569595 N, 102.2304875 E
Address:
NEAR KAMPUNG DALAM PANDAN , 16200 , WAKAF BHARU , KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Direct connection of Classic Malay House and Modern Malay House
Major Material:
- Singgora Tile, Concrete
Significant Features:
- Material: Well-preserved wood material
Historical Background : N/A
Remark:
- Rarely occupied (Only in Eid Fitri)
- Upper timber living quarters with a semi-open ground-level zone
15. Rumah @ Near Kampung Dalam Pandan
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1569311 N, 102.2306803 E
Address:
NEAR KAMPUNG DALAM PANDAN , 16200 , WAKAF BHARU , KELANTAN
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Singgora Tile
Significant Features:
- Material: Well-preserved wood material
- Space Use: Kolong rumah used to store things
- Structure: Dinding susun sireh
Historical Background : N/A
Remark:
- Rarely occupied (Only in Eid Fitri)
- A core house expanded through layered, small-scale extensions
16. Rumah @ Jalan Kampung Laut 2 (No. 16040)
Building Owner: N/A
Year: N/A
Architect: N/A
Coordinate: 6.1569295 N, 102.2298924 E
Address:
16040 , JALAN KAMPUNG LAUT 2 , 16210 , WAKAF BHARU , KELANTAN
Building Typology: Residence
Building Condition: Abandoned
Architectural Style: Transitional Period Architecture (Era Peralihan)
Major Material:
- Singgora Tile
Significant Features:
- Material: Well-preserved wood material
- Structure: Tetupai cicak
Historical Background : N/A
Remark:
- Rarely occupied (Only in Eid Fitri)
- A house with a front-added service/utility block ( the concrete porch )
17. Rumah @ Jalan Masjid Lama (No. 271)
Building Owner: Nasi Berlauk Ajik House
Year: 1977
Architect: N/A
Coordinate: 6.15744 N, 102.231473 E
Address:
271, JALAN MASJID LAMA, KAMPUNG LAUT 2
Building Typology: Shop
Building Condition: Well Maintained
Architectural Style: Modern Malay House
Major Material:
- Brick, Wood
Significant Features: N/A
Historical Background : N/A
Remark: N/A
18. Rumah @ Jalan Masjid Lama (No. 235)
Building Owner: Mohd Noor Bin Wan Mamat
Year: 2010
Architect: N/A
Coordinate: 6.157222 N, 102.231193 E
Address:
235, JALAN MASJID LAMA, KAMPUNG LAUT 2
Building Typology: Residence
Building Condition:
Well Maintained ; Part of roof repaired (From SInggora roof to zinc roof)
Architectural Style: Modern Malay House
Major Material:
- Brick, Wood
Significant Features:
- Material: Extend by using brick and concrete material
Historical Background : N/A
Remark: N/A
19. Rumah @ Jalan Masjid Lama (No. 227)
Building Owner: Che Yusoff Bin Ismail
Year: N/A
Architect: N/A
Coordinate: 6.157145 N, 102.231062 E
Address:
227, JALAN MASJID LAMA, KAMPUNG LAUT 2
Building Typology: Residential & Serunding Factory
Building Condition: Well Maintained
Architectural Style: Traditional Malay House
Major Material:
- Brick, Wood
Significant Features: N/A
Historical Background :
It used to be a house but now divided into 2 houses. One is looked after by owner's wife and the other is rented out to someone else
Remark: N/A
20. Rumah @ Jalan Masjid Lama (No. 237)
Building Owner: Asri Husin
Year: 1995
Architect: N/A
Coordinate: 6.156976 N, 102.2313 E
Address:
237, JALAN MASJID LAMA, KAMPUNG LAUT 2
Building Typology: Residence
Building Condition: Well Maintained
Architectural Style: Modern Malay House
Major Material:
- Brick, Wood
Significant Features:
- Space Use: Space below the stilt house is fully be used and enclosed with brick wall
Historical Background :
Before the construction of the retaining wall (2014), the house was flooded to the point when it filled the ground floor
Remark: N/A
21. Azrini Serunding
Building Owner: N/A
Year: 1995
Architect: N/A
Coordinate: 6.156635 N, 102.231271 E
Address:
237, JALAN MASJID LAMA, KAMPUNG LAUT 2
Building Typology: Serunding Factory
Building Condition:
Well Maintained ; Renovated (Added front part)
Architectural Style: Transitional Period Architecture (Era Peralihan)
Major Material:
- Brick, Corrugated Zinc Roofing
Significant Features:
- Structure: Metal structure roofing
- Material: Wall is made up with brick and the door is made by zinc
Historical Background : N/A
Remark: N/A
